Joan 13 - Technical specifications

13

Display

  • 13.3-inch (4:3 diagonal) non-touch E Ink® Carta electronic paper screen
  • High visibility and contrast
  • 180 viewing angle
  • Resolution: 1600 x 1200 pixels
  • Active Area (H/W): 10.64 x 7.98 in (270.4 x 202.8 mm)
  • Pixel Pitch (H/W): 0.006 x 0.006 in (0.169 x 0.169 mm; equivalent to 150 ppi
  • Pixel Configuration: Rectangle
  • 16-level grayscale
  • Refresh rate: 750 ms (4 bit full screen) / 100 ms (1 bit partial)

Connectivity

  • 2.4/5 GHz Wi-Fi (IEEE 802.11 a/b/g/n) standard, WPA2-PSK, WPA3 Personal, WPA2 Enterprise support

  • 2.4 GHz Bluetooth 5 support

    *Please note, Joan 13 devices produced prior to 2021 can only operate at a frequency of 2.4 GHz

Power

  • Patented ultra-low energy architecture, only 1% of the power used by LCD
  • Enclosed Micro-USB charging cable
  • Cordless functionality

High-performance rechargeable Lithium-Polymer 10,800 mAh battery (2x LP578499-PCM-LD; 5,400 mAh @ 3.7V) . Up to 12 months of autonomy on a single battery charge. 10 hours charging time with a Micro-USB charger (output rating of 5 V, 1 A).
CAUTION. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Calendar Compatibility

  • Google Workspace (Former Google Apps; Google Calendar; G Suite)
    • OAuth2 authentication
  • Office 365 (Exchange Online)
    • OAuth2 authentication
  • Microsoft Exchange (Outlook)
    • Basic authentication
    • NTLM proprietary authentication protocol
  • iCalendar (.ics)

Dimensions & weight

  • 9.05 x 11.40 x 0.39 in (230 x 297 x 10.05 mm)
  • Joan with back magnet 33.5oz (950 g)

Casing

  • High-quality anodized aluminum casing
  • Anti-reflective, high transmissive glass
  • Color: Black, Gray

Mounting

  • Attachable to any surface with a self-adhesive Magnetic Mount that requires no tools (one included with each device, additional Magnetic Mount 5-Packs available for purchase).
  • 3.94 x 3.94 in (100 x 100 mm) VESA mount compliant
  • Devices can be mounted at a maximum height of 2m

Environmental conditions

  • Operating and storage temperature range: 32°F to 122°F (0°C to +50°C)
  • During charging, the temperature should not exceed 113°F (45°C)
  • Indoor use only

Available in plan

  • Essentials
  • Professional
  • Enterprise

In the box

  • 13.3-inch wireless Joan device
  • 1 x Magnetic Mount for easy installation
  • 1 x Micro-USB cable for configuration and charging
  • Access to the Joan Web Portal
