How to configure Joan devices

The latest Joan devices are Bluetooth enabled, thus allowing the configuration via the mobile app.

If your device does not have Bluetooth or you wish to configure it using USB cable, you can download the Joan Configurator for desktop application here.

The Joan Configurator for mobile app is available for iOS and Android.

  • Search for Joan Configurator in Google Play Store or scan the QR code below with your Android smartphone.
    qrCodeAndroidStore
  • Search for Joan Configurator in AppStore or scan the QR code below with your iPhone.

        qrCodeAppStore

If you just got a brand new Joan device, please wake the Bluetooth module up. When shipped, the devices are in special, deep sleep mode. You can wake it up by plugging the device with the supplied USB cable into the computer or by using the power brick (not included with the device) to electricity.

How to configure the device

  1. Open the Joan Configurator mobile app.
  2. Once opened, the app will automatically scan for nearby Joan devices via Bluetooth. If prompted, please enable permissions and turn on Bluetooth and location on your smartphone.
    If the app does not automatically scan for devices, simply tap “Scan
  3. After a successful scan, a list of all nearby Joan devices will appear.
    2022-07-18_20-52

  4. Locate the Joan device which you wish to configure and tap on it.
  5. You will be prompted with a Bluetooth pairing request. You will need to accept the request in order to connect to the Joan device
  6. Once paired, the app will begin reading data from the device and a LED backlight will turn on the device's screen.
    2022-07-18_21-12 2022-07-18_21-13

  7. To start configuring the Wi-Fi, click on Search WiFi, and wait for the Joan device to scan all Wi-Fi networks nearby. If the network that you wish to connect to is hidden, simply type in the SSID in the field at the top.
  8. Select the security type of the network. Joan supports WPA2-PSK and, WPA2-EAP or Open.
  9. Enter the password of the network (for WPA2-PSK) or for enterprise security (WPA2-EAP) set the correct details required by your network.

  10. The hosting cloud server will be automatically set. If you wish to change it, tap on Advanced connectivity, then, click on Cloud servers to select the desired server from the provided list.

    In case you wish to connect the device to an on-premises server, enable the Static IP toggle button, and enter the IP of your server and other required information.
    Once satisfied with the input, tap “Connect” at the top.
    2022-07-18_21-20


And that’s it! The device will now begin the configuration process and connect to the Wi-Fi and the desired server.



Alternative configuration options

For older devices without Bluetooth please use see this article on how to configure the device with a USB cable.

Should you experience any issues during the configuration process, double-check the network credentials. If this does not resolve it, please take a screenshot of the error you are seeing in the app, and send it along with the device logs to support@getjoan.com.
